PL 6100
Single Printhead - High Resolution
Ultimate Precision, Exquisite Details & Smooth Surface Finish
High Resolution
2900 X 2900 X 1700 dpi
Layer Thickness 15 µm
Material Capacity
3.0 Kg Build Material (2 X 1.5 Kg Bottle)
3.2 Kg Support Material (2 X 1.6 Kg Bottle)
Durable Flexible Wax
Excellent dimensional stability and is ideal for, filigree, chains and complex, high-value casting
24/7 Printing
Unattended & Continuous
.png)
Single Printhead
Printing Speed of 6.35 mm/h Single Lane Job
2.50 mm/h for a 3 Lane Job
Large Build Volume
290 X 207 X 100 mm
User-Friendly Workflow
all-in-one software that simplifies digital jewellery file slicing. composing and printing procedures for beginners.
Easier Post-Processing
Contact-Free Support Removal
High Precision - Professional Wax 3D Printer for Jewellery Manufacturing
The Plempire PL 6100 is a high-precision, single-printhead wax 3D printer engineered specifically for professional jewellery manufacturing. This sophisticated device features ultra-high accuracy, an expansive build volume, and optimized material efficiency, facilitating rapid and dependable production of detailed wax models.
The PL 6100 is particularly suitable for jewellery manufacturers and 3D printing service providers seeking outstanding precision and enhanced production efficiency within their operations. Employing MultiJet Printing (MJP) technology, the PL 6100 achieves exceptional precision, making it ideal for complex jewellery applications. With a build volume of 290 × 207 × 100 mm, it delivers dimensional consistency of approximately ±0.04 mm per 20 mm. Its remarkable resolution (2900 × 2900 × 1700 DPI) and fine 15 μm layer thickness enable the fabrication of intricate, high-accuracy jewellery components.
User-Friendly Workflow
The PL 6100 is designed for continuous 3D printing with reliable, long-term performance. It features advanced safety, smart monitoring, and user-friendly software for efficient workflow. The contact-free support removal system prevents damage and simplifies post-processing by allowing easy detachment of supports from models.
Ultimate Precision
The PL6100 Ultimate Precision offers exceptional accuracy and reliability for 3D printing. It consistently produces models true to their dimensions and details, with minimal errors. Advanced motion control and quality stepper motors ensure smooth surfaces and sharp features, while sturdy construction and calibration help deliver dependable, high-quality prints.
Stronger, Flexible, Smooth Models
Plempire’s PL 6100 uses patented Multi Jet Printing (MJP) technology to set a new standard for jewellery manufacturing. It produces high-resolution prints with smoother surfaces, improving quality and reducing post-processing by up to 33%. This allows jewellery makers to cut labour costs, speed up production, and increase competitiveness.
Technical Information
Printer Technical Information
Printing Technology
MultiJet Printing (MJP)
Build Volume
290 X 207 X 100 mm
Printing Mode
QHD: 2900 X 2900 X 1700 DPl
Layer Thickness:
15 um
Dimensional Accuracy
±0.04mm / 20mm
Power supply
AC 220-240v, 50 / 60 Hz 23A
Machine Dimensions
1310 X 770 X 1670 mm
Net Weight
486 kg
Gross Weight (with crate)
673 kg
Crate Size
1650 X 1000 X 1880 mm
Slicing Software
PL3DPrint
Supported File Format
STL, SLC, OBJ
Email Notification
√
Hard Disk Capacity
500 Giga
Connectivity
RJ-45/UsB
Supported Operating System
Windows 7, 10 (64bit), 11 (64bit)
Working Environment
18-26°C; humidity: 30-70%
Material Properties
Material Name
YHK-803R
YHK-102
-
Description
Casting Wax
Soluble Wax
-
Material Type
Part
Support
-
Net Weight
1.5 kg/bottle
1.6 kg/bottle
-
Composition
100% Wax
100% Wax
-
Colour
Red
White
-
Density @ 95°C (Liquid)
0.811 g/ml
0.85g/ml
-
Melting Point
68℃
55℃
-
Softening Point
63℃
-
-
Volumetric Shrinkage
1.18%
-
-
Linear Shrinkage
0.52%
-
-
Needle Penetration Hardness
7.2
-
-
Ash Content
<0.019%
-
-
