PL 2000 Plus
Single Printhead - 2 Mode Printing & 2 Part Materials Choice
High Resolution - 2 Print Settings
XHD: 1200 X 1200 X 1600 dpi (16 µm Layers)
ZHD: 1200 X 1200 X 3200 dpi (8 µm Layers)
Material Capacity
2.4 Kg Build Material (2 X 1.2 Kg Bottle)
2.7 Kg Support Material (2 X 1.35 Kg Bottle)
2 Options of Wax Part Material
Excellent dimensional stability and is ideal for, jewellery & industrial applications.
24/7 Printing
Unattended & Continuous
Single Printhead
High Precision
Excellent Surface Quality.
Large Build Volume
294 X 212 X 150 mm
User-Friendly Workflow
all-in-one software that simplifies digital jewellery file slicing. composing and printing procedures for beginners.
Easier Post-Processing
Contact-Free Support Removal
Professional Wax 3D Printing for Jewellery & Industrial Applications
The Plempire PL 2000 is an advanced 3D printer engineered for precision wax modelling, making it highly suitable for jewellery design and industrial prototyping. Employing sophisticated jetting technology, it produces detailed and smooth wax patterns ideal for lost-wax casting processes.
The PL 2000 is recognised for its reliability and efficient performance, enabling designers to create complex geometries and fine features with exceptional accuracy, thereby optimising workflows and minimising production times. Its robust construction and intuitive interface facilitate seamless operation, and its advanced capabilities provide a competitive advantage in the marketplace. The versatility and efficiency of the Plempire PL 2000 ensure consistent results, making it an invaluable tool for professionals seeking precision and streamlined modelling tasks.
Exceptional Performance
The PL 2000 delivers outstanding performance and increased production capabilities. It supports two printing modes with layer thicknesses of 16 µm and 8 µm, and can use two distinct part materials, making it suitable for both industrial applications and jewellery pattern manufacturing. Its versatile features make it an excellent option for manufacturers who want to uphold high-quality standards.
Better Than Ever
The PL 2000 wax 3D printer distinguishes itself in the industry due to its impressive speed and operational efficiency.
Known for its dependable performance, this printer is an excellent option for manufacturers needing high-volume production while maintaining quality and accuracy. It presents an ideal solution for both jewellery and industrial manufacturers who aim to optimise their workflow and boost productivity.
Stronger & Flexible Models
The PL 2000 is capable of printing with two types of wax materials, making it suitable for both large, bulky parts and jewellery production, especially when using the YHK-803R red flexible wax. Its refined detailing improves the quality and appearance of patterns while reducing the need for extensive post-processing, which shortens post-processing time. As a result, jewellery manufacturers can lower labour costs and accelerate production.
Technical Information
Printer Technical Information
Printing Technology
MultiJet Printing (MJP)
Build Volume
294 X 212 X 150 mm
Printing Mode - XHD
1200 X 1200 X 1600 DPl
Printing Mode - ZHD
1200 X 1200 X 3200 DPl
Layer Thickness:
16 um (XHD) / 8 um (ZHD)
Dimensional Accuracy
±0.04mm / 20mm
Power supply
AC 220-240v, 50 / 60 Hz 23A
Machine Dimensions
1272 X 780 X 1210 mm
Net Weight
320 kg
Gross Weight (with crate)
430 kg
Crate Size
1650 X 1000 X 1880 mm
Slicing Software
PL3DPrint
Supported File Format
STL, SLC, OBJ, AMF, MJPDDD
Email Notification
√
Hard Disk Capacity
500 Giga
Connectivity
RJ-45/UsB
Supported Operating System
Windows 7, 10 (64bit), 11 (64bit)
Working Environment
18-26°C; humidity: 30-70%
Material Properties
Material Name
YHK-801R
YHK-601
YHK-102
Description
Casting Wax
Casting Wax
Soluble Wax
Material Type
Part
part
Support
Net Weight
1.2 kg/bottle
1.2 kg/bottle
3.6 kg/bottle
Composition
100% Wax
100% Wax
100% Wax
Colour
Red
Purple
White
Density @ 95°C (Liquid)
0.811 g/ml
0.811 g/ml
0.85g/ml
Melting Point
68℃
68℃
55℃
Softening Point
63℃
63℃
-
Volumetric Shrinkage
1.18%
1.18%
-
Linear Shrinkage
0.52%
0.52%
-
Needle Penetration Hardness
7.2
7.2
-
Ash Content
<0.019%
<0.019%
-
